Select the Series 2000 Magnehelic® Differential Pressure Gages for a versatile low differential pressure gage with a wide choice of 81 models and 27 options to choose from. Using Dwyer's simple, frictionless Magnehelic® gage movement, it quickly indicates air or non-corrosive gas pressures--either positive, negative (vacuum) or differential. The design resists shock, vibration, over-pressures and is weatherproof to IP67.
Select the –HA High Accuracy Magnehelic® gage option for an accuracy within 1% of full-scale. Also included with the –HA option at no extra cost are a mirrored scale overlay and a 6 point calibration certificate.
Differential Pressure Gage: 0-60" w.c.
- Easy to read gage through undistorted plastic face permits viewing from far away
- Patented design provides quick response to pressure changes means no delay in assessing critical situations
- Durable and rugged housing and high-quality components combine to provide long-service life and minimized down-time
- High accuracy option is twice as accurate as the standard Magnehelic® gage
- Accuracy: ± 2 %
- Accuracy Detail: ± 2% (-HA model ± 1) of FS (± 3% (-HA ± 1.5%) on -0, -100PA, -125PA, -10MM and ± 4% (-HA ± 2%) on -00, -60PA, -6MM ranges), throughout range at 70°F (21.1°C)
- Compliance: RoHS 2
- Compliance Note: Meets the technical requirements of EU Directive 2011/65/EU (RoHS II). Note: -SP models not RoHS approved
- Dial Dia: 4 in
- Dual: false
- Enclosure Ratings: IP67
- Material Construction Option: Standard
- Materials: Aluminum, Acrylic
- Materials, Wetted: Consult Factory
- Measurement Pressure Type: Differential
- Measurement Pressure, Max: 60 inH²O
- Measurement Pressure, Min: 0 inH²O
- Media Compatibility: Air, Argon, Carbon dioxide, Helium, Nitrogen, Non-Corrosive Dry Gases
- Mounting Orientation: Vertical Diaphragm
- Operating Temperature, Max: 140 °F
- Operating Temperature, Min: 20 °F
- Pressure Limits: -20 inHg to 15 psig
- Process Connection Note: +1/8" female NPT duplicate high and low pressure taps - one pair side and one pair back
- Process Connection Size: 1/8 in
- Process Connection Type: NPT Female
- Safety Features: Relief plug opens at approximately 25 psig (1.72 bar), standard gages only
- Weight: 510 g
Applications
- Filter monitoring
- Air velocity with Dwyer® pitot tube
- Blower vacuum monitoring
- Fan pressure indication
- Duct, room or building pressures
- Clean room positive pressure indication
Each Unit Includes
- 1 - Differential Pressure Gage(2060)
