Benchtop Oscilloscopes for the Lab



Imagine having a digital storage oscilloscope (DSO) on the bench with next-generation capabilities. Transcat makes it possible with an diverse selection of benchtop oscilloscopes from manufacturers such as Keysight, Rigol, and Siglent. Our digital bench oscilloscope models offer greater memory depth for capturing single-shot and repetitive signals. They allow you to find glitches and transient events. In fact, you’ll find industry-leading waveform update rates, touch screens, fast triggering and advanced memory technology. We provide the top DSOs with multiple channels or mixed signal capabilities for debugging, electronic analysis, equipment testing, and manufacturing design.



Buy Calibrated Benchtop Oscilloscopes to Reduce Your Downtime



 Because Transcat operates dozens of ISO 17025 Accredited Calibration Labs across the United States and Canada, we are uniquely positioned to offer new instrument calibration services on most of the items we distribute.  If your quality system requires that your instruments have a valid calibration certificate at all times, take advantage of our oscilloscope calibration capabilities so that your instrument arrives ready to be put into use.



How to Select the Right Bench Oscilloscope



 When browsing benchtop oscilloscopes, you’ll want to think about the signals to be captured. Are they analog or digital? High-speed? Primary selection specifications include the instrument’s bandwidth, memory depth and sampling rates. Additional considerations include triggering options, input ranges, and resolution. Bandwidth tells you the maximum frequency that a bench oscilloscope can measure with accuracy. For digital signals, a scope’s bandwidth should normally be five times the max signal bandwidth. Remember, you’ll see greater signal detail when using a scope with a faster waveform update rate. Also, upgradability means you can add bandwidth or digital channels later.



High Performance Keysight Benchtop Oscilloscopes



 Keysight Technologies 3000T X-Series oscilloscopes are 5-in-1 bench instruments delivering: an oscilloscope, digital channels, waveform generation, a digital voltmeter and a protocol analyzer. Keysight’s 6-in-1 bench model delivers greater signal detail with the industry’s fastest waveform update rate. The company’s 2000 X-Series is an entry-level line that leads its class with a large screen, deep memory and valuable options.



Compare the Specs from Top Keysight Scopes with Transcat’s Keysight Oscilloscope Selection Guide



Choose Rigol for Powerful Scopes at Entry-Level Pricing



 Rigol employs innovative technology to manufacture economical Digital Oscilloscopes featuring broad debugging and testing capabilities and seven-inch displays. All Rigol scopes feature a best-in-class cost/performance ratio, including:

  • Bandwidth up to 1GHz
  • Memory up to 140 Million Points
  • Sampling up to 5GSa/s
  • Features such as FFTs, Persistence, Zoom, X-Y Plots and roll/record modes

Check out the Rigol DSO1000E series for an entry level 1GSa/s bargain, or the DS4000 for a powerful, yet affordable 4GSa/s scope.



Product

Channels

Bandwidth

Sample Rate

DS6000

4 analog channels

600 MHz - 1 GHz

5 GSa/s

MSO4000

4 analog / 16 logic

100-500 MHz

4 GSa/s

DS4000

4 analog channels

70-300 MHz

4 GSa/s

MSO2000A

2 analog / 16 logic

70-300 MHz

2 GSa/s

DS2000A

2 analog channels

70-100 MHz

2 GSa/s

MSO1000Z

4 analog / 16 logic

50-100 MHz

1 GSa/s

DS1000Z

4 analog channels

50-100 MHz

1 GSa/s

DS1000D

2 analog / 16 logic

50-100 MHz

1 GSa/s

DS1000E

2 analog channels

50-100 MHz

1 GSa/s





Be bench-ready by ordering today. To learn more, chat with a rep, send us a message, or call 800.828.1470.

.

Read More

Compare up to 5 Items

You have no items to compare.

Keysight Score 2 Scopes for the Price of 1!

List Grid

Items 1-25 of 276

Set Ascending Direction
Page:
  1. 1
  2. 2
  3. 3
  4. 4
  5. 5
  1. Siglent SDS1102X+

    200MHz Oscilloscope w/2 Analog Channels & 16 Dgtl.Channels

    Order #: SDS1102X+

    Mfg #: SDS1102X+

    Ships in 2-3 weeks

    $899.00 USD

    $653.00 USD

  2. Keysight Technologies EDUX1002A

    InfiniiVision 1000X Edu. Oscilloscope,50MHz,1GS/s,2Ch

    Order #: EDUX1002A

    Mfg #: EDUX1002A

    In stock

    $448.00 USD
  3. Keysight Technologies EDUX1002G

    InfiniiVision1000X Oscilloscope w/WaveGen,50MHz,1GS/s,2Ch

    Order #: EDUX1002G

    Mfg #: EDUX1002G

    In stock

    $647.00 USD
  4. Keysight Technologies DSOX1102A

    InfiniiVision1000X Oscilloscope 70/100 MHz,2-Channel

    Order #: DSOX1102A

    Mfg #: DSOX1102A

    In stock

    $647.00 USD
  5. Keysight Technologies DSOX1102G

    InfiniiVision1000X Oscilloscope w/WaveGen,70/100MHz,2Ch

    Order #: DSOX1102G

    Mfg #: DSOX1102G

    In stock

    $847.00 USD
  6. Siglent SDS1000X-LA

    16 Channel MSO (Software) for SDS-1000X Oscilloscopes

    Order #: SDS1000X-LA

    Mfg #: SDS1000X-LA

    Ships in 2-3 weeks

    $119.00 USD
  7. Keysight 3000T Digital Oscilloscopes

    Keysight Technologies 3000T X-Series Oscilloscope

    Order #: Keysight Technologies 3000T X-Series Oscilloscope

  8. Keysight 3000A-Series Oscilloscopes

    Keysight Technologies 3000A X-Series Oscilloscope

    Order #: Keysight Technologies 3000A X-Series Oscilloscope

  9. Keysight 4000X Digital Oscilloscopes

    Keysight Technologies 4000 X-Series Oscilloscope

    Order #: Keysight Technologies 4000 X-Series Oscilloscope

  10. Keysight 1000 Digital Oscilloscopes

    Keysight Technologies 1000 Series Oscilloscope

    Order #: Keysight Technologies 1000 Series Oscilloscope

  11. Keysight 2000X Digital Oscilloscopes

    Keysight Technologies 2000 X-Series Oscilloscope

    Order #: Keysight Technologies 2000 X-Series Oscilloscope

  12. Keysight 6000X Digital Oscilloscopes

    Keysight Technologies 6000 X-Series Oscilloscope

    Order #: Keysight Technologies 6000 X-Series Oscilloscope

  13. Keysight 6000-Series Oscilloscopes

    Keysight Technologies 6000 Series Oscilloscope

    Order #: Keysight Technologies 6000 Series Oscilloscope

  14. Rigol DS1000D Digital Oscilloscope

    Rigol DS1000D Series Mixed Signal Oscilloscopes

    Order #: Rigol DS1000D Series Mixed Signal Oscilloscopes

  15. Rigol DS1000E Digital Oscilloscope

    Rigol DS1000E Series Digital Oscilloscopes

    Order #: Rigol DS1000E Series Digital Oscilloscopes

  16. Rigol DS1000Z Digital Oscilloscope

    Rigol DS1000Z Series Digital Oscilloscope

    Order #: Rigol DS1000Z Series Digital Oscilloscope

  17. Rigol MSO1000Z Digital Oscilloscope

    Rigol MSO1000Z Series Mixed Signal Oscilloscope

    Order #: Rigol MSO1000Z Series Mixed Signal Oscilloscope

  18. Rigol DS2000A Digital Oscilloscope

    Rigol DS2000A Series Digital Oscilloscope

    Order #: Rigol DS2000A Series Digital Oscilloscope

  19. Rigol MSO2000A Digital Oscilloscope

    Rigol MSO2000A Series Mixed Signal Oscilloscope

    Order #: Rigol MSO2000A Series Mixed Signal Oscilloscope

  20. Rigol DS4000 Digital Oscilloscope

    Rigol DS4000 Series Digital Oscilloscope

    Order #: Rigol DS4000 Series Digital Oscilloscope

  21. Rigol MSO4000 Digital Oscilloscope

    Rigol MSO4000 Series Mixed Signal Oscilloscope

    Order #: Rigol MSO4000 Series Mixed Signal Oscilloscope

  22. Rigol DS6000 Digital Oscilloscope

    Rigol DS6000 Series Digital Oscilloscope

    Order #: Rigol DS6000 Series Digital Oscilloscope

  23. RIGOL DS6102

    1GHz Digital Oscilloscope w/2 Channels,5GSa/sec,Dynamic Mode

    Order #: DS6102

    Mfg #: DS6102

    Ships in 3-4 weeks

    $8,274.00 USD
  24. Keysight Technologies DSOX3054T

    Oscilloscope,4-Channel,500MHz 8.5" Capacitive Touch Screen

    Order #: DSOX3054T

    Mfg #: DSOX3054T

    In stock

    $11,670.00 USD
  25. RIGOL DS1054Z

    50MHz Digital Oscilloscope w/4 Channels & 12Mpt Memory/Connect

    Order #: DS1054Z

    Mfg #: DS1054Z

    In stock

    $399.00 USD
