Dwyer Instruments 25021

Series 2500 Temp controller RTD JKT input, SSR output, no alarm

The Series 2500 Temperature Control provides an impressive array of features in an economical 1/4 DIN package. Features include on-off, time proportioning, proportional, PI, PD, or full PID control, programmable from the front panel, or use Self-Tune PID. Input types are selectable from a variety of thermocouple types (J, K, T, E, N, or L) or DIN, NIST, or Ni RTD's. Outputs include solid state relay, mechanical relay, 5 VDC (ideal for driving an external SSR), or isolated 4-20 mA proportional current. Programmable alarm can act as high or low or high/low guard band alarm. A water and corrosion resistant front panel (NEMA 4X; IP65), input fault timer, digital input filter, Self-Tune ramp to setpoint, four password protected security levels, and °F or °C display selection are all standard. Entire electronics package is field replaceable without wiring changes thanks to removable front panel.

Order #: 25021

Mfg Part #: 25021

$539.00 USD

$522.83 USD


Usually ships in 7-10 days

Free shipping over $250

Add Items to Cart

Request a Calibration Quote

Transcat can calibrate your existing instruments.

Request a Calibration Quote

Rent From Transcat

Do you need a test instrument for a short time?

Request a Rental Quote

click on image to view gallery image(s)

View All Dwyer Instruments Products

Overview :

Product Highlights

  • Input: RTD
  • Output: SSR
  • Alarm: No
  • Inputs: Thermocouple or RTD
  • Input Impedance:Thermocouple = 3 megohms minimum, RTD current = 200µA maximum
  • Display: Two 4-digit, 7 segment, 0.56" high LED
  • Resolution: 1 degree or 0.1 degree
  • Accuracy: ±0.25% of span, ±1 degree
  • Supply Voltage: 100-240 VAC nominal, ±10%, 50-400 Hz, single phase; 132-240 VDC nominal, ±10%
  • Power Consumption: 5 VA maximum
  • Operating Temperature: 14 to 131°F (-10 to 55°C)
  • Memory Backup: Non-volatile memory - no batteries required
  • Control Output Ratings: SSR: 2.5A @ 240 VAC resistive at 77°F (25°C), de-rates to 1.25A @ 130°F 55°C); Relay: SPDT, 10 A @ 240 VAC resistive; Switched Voltage (non-isolated) 5 VDC @ 20 mA; Proportional Isolated Current: 0-20 mA, selectable, into 600 Ohms maximum
  • Control Action: Selectable for reverse (usually heating) or direct (usually cooling)
  • Ramp: One ramp time adjustable from 0-100 hours
  • Isolation :Relay and SSR outputs; 1500 VAC. 0-20 mA output; 500 VAC. 5 VDC output is not isolated
  • Weight: 13 oz (369 g)
  • Front Panel Rating: NEMA 4X (IP65)
